Features:
● New Crazy bee F4 PRO V2.0 AIO Flight controller 2 - 3s Lipo Compatible
● 2S for indoor Cine whoop mode
● 3S for outdoor Freestyle whoop mode
● Beta-flight support, multi-flight mode: ACRO / AIR / ANGLE
● The lightest 1102 brushless motor only 2.7g with double ball bearings
● Powerful and smoothly
● Beta flight OSD support, easy to get RSSI, Voltage, current from your goggles ( DSMX version no RSSI output )
● Caddx turtle v2 + 1080p 60fps DVR ready
● Camera angle adjustable
● VTX power switchable 25mw - 200mw
● Smart audio ready, change VTX bands, powers, channels via OSD
● Special Breath light ready
● Real Bind and Fly version
● Compatible both for 2s - 3s Lipo / LIHV
Optional Receiver:
● Frsky Non-EU version support NON-EU Frsky transmitter D8 / D16 compatible
● Flysky version support both AFHDS and AFHDS-2A protocol transmitter
● DSM2 / DSMX version support DSM2 and DSMX compatible Spectrum transmitter
● No RX version support external serial-bus receiver like xm+, crossfire, S-FHSS etc..
● Full telemetry function ready ( Frsky Non-EU and Flysky version support )
Specifications:
Motor
- Mode: EX1102 KV10000
- Configuration: 9N 12P
- Stator Diameter: 11mm
- Stator Length: 2mm
- Shaft Diameter: 1mm
- Motor Dimension ( Dia. x Len ): 13.5mm x 16mm
- No.of Cells( Lipo ): 1S - 3S
Flight controller
- ( Frsky version ) CRAZYBEE F4FR PRO V2.0 Firmware target: CrazybeeF4FR
- ( Flysky version ) CRAZYBEE F4FS PRO V2.0 Firmware target: CrazybeeF4FS
- ( DSM2 / DSMX version ) CRAZYBEE F4DX PRO V2.0 Firmware target: CrazybeeF4DX
- ( No RX version ) CRAZYBEE F4 PRO V2.0 Firmware target: CrazybeeF4DX
- MCU:STM32F411CEU6 ( 100MHZ, 512K FLASH )
- Sensor: MPU-6000 ( SPI connection )
- Board size: 28.5 x 28.5MM
- Power supply: 1 - 3S battery input ( DC 3.5 - 13V )
- Built-in 5A ( each ) Blheli_S 4in1 ESC Dshot600 ready
- Frsky version Built-in SPI Frsky receiver with telemetry ( D8 / D16 switchable )
- Flysky version Built-in SPI Flysky receiver with telemetry ( AFHDS / AFHDS2A switchable )
- DSM2 / X Version built-in Serial-based DSM2 / DSMX compatible satellite receiver
- No RX version need to add external Receiver
- Built-in Beta flight OSD ( SPI Control )
- Built-in Current meter Max 28A
- Current meter scale set to 1175
- Built-in 5V 1A Buck / Boost with LC filter
- Built-in voltage detection
Onboard 4in1 ESC
- MCU upgraded to EFM8BB21
- Power supply: 1-3S LiPo / LiPo HV ( 3.5v / 13v )
- Current: 5A continuous peak 6A ( 5 seconds )
- Support BLHeliSuite programmable
- Factory firmware: S_H_50_REV16_7.Hex
- Default protocol: DSHOT600
Frsky NON-EU receiver Version
- SPI BUS receiver
- Frsky D8 / D16 switchable
- Compatible Non-EU transmitter both D8 and D16 mode
- Channels: 8ch or 16ch
- Failsafe support
- No ground interference ( Transmitter and receiver 1 m from the ground ): 300m
Flysky receiver Version
- SPI BUS receiver
- Protocol: AFHDS and AFHDS-2A Switchable
- Channels: 8ch ( AFHDS ) or 14ch ( AFHDS-2A )
- No ground interference ( Transmitter and receiver 1 m from the ground ): 300m
- Failsafe support
DSM2 / DSMX receiver version
- Serial bus receiver
- Protocol: DSM2 / DSMX compatible
- Channels: 6 - 9 ( Depend on your radio )
- No ground interference ( Transmitter and receiver 1 m from the ground ): 300m
PNP No RX version
- No RX version support external serial-bus receiver like xm+, crossfire, S-FHSS etc.
VTX
- Output power: 25 - 200mw switchable
- Frequency: 40CH
- Input voltage: 3.3V 5.5V
- Current consumption: 300mA ( type )
- Antenna: RG178 antenna
- Frequency: 5.8GHz 5bands 40 channels
- With Race land
- Smart audio ready
- Weight: 3g
CADDX Turtle V2
- Image sensor: 1 / 2.7 inch CMOS sensor
- Horizontal: 800TVL
- TV system: NTSC / PAL changeable
- Video Resolution: 1080P 60fps / 1080P 30fps / 720 60fps
- Power Input: DC 4.5 - 20V
- FPV FOV: 155 degrees
- Recording FOV: 170 degrees
- Mini Illumination: 0.01lux
- Image Resolution: 2 Megapixels
- Lens: 1.8mm Turbo Eye Lens
- Working Current: 380mA 5V / 160mA 12V ( low consumption )
- OSD Menu: Yes ( Support Voltage Display )
- Video Files: MP4
- Audio: Support
- Electronic Shutter: PAL : 1 / 50 - 100,000; NTSC : 1 / 60 - 100,100
- S / N Ratio: more than 60dB ( AGC OFF )
- Video Output: CVBS
- Max Micro SD Card Supported: 8 - 64GB ( need Class 10 or above, recommend Class 10 / UHS-I / UHS-II )
- Color: Red
Lipo Battery
- Capacity: 300mAh
- Voltage: 11.4v
- Continuous Discharge Rate: 30C
- Instantaneous discharge rate: 60C
- Size: 65mm x 18mm x 11mm
- Weight: 23g
- Connector: XT30
- Charging time: 35 - 50min
- Using time: 10min
