XA10 USB Bar Code Scanner Compatible With Multiple Operation System Handhold Laser Scanner For Supermarket Bookstore Hospital Logistics Company Etc.
XA10 USB Bar Code Scanner is equipped with USB 2.0 high speed ARM CPU, and compatible with all operation systems. It supports the built-in automatic identification USB, PS2 keyboard, RS-232 serial port and USB virtual serial port with 200 times per second ultra-strong error correcting capability and ultra-fast scanning speed. This bar code scanner is easy to use with hand-held design, and with universal applications for places like supermarket, shops, bookstore, hospital, library, office, logistics, etc.
Features:
Excellent Decoding Ability: It Can decode EAN-8, EAN-13, UPC-A, UPC-E, Code39, Code93, Code 128, EAN128, Codaber, Industoal2of5, Interleave2of5, Matrix2of5, MSI etc. Besides, some code which is difficult to decode such as a little damaged and silvery code can also be decoded by XA10.
Plug and Play: No driver needed, just connect the bar code scanner via your computer's USB port, and you can use it instantly and easily.
Two scanning modes: One is manual trigger to begin scanning, the other is automatic mode for scanning continuously and quickly.
Multiple uses: Can be used in different places and trades such as hospitals, supermarkets, bookstores, retail shops, postal service, financial industry, middle and small scale logistics industry.
Lightweight Hand-held Design: Small and light, which just fits the hand well, you will feel more comfortable when hold it for use.
Anti-shock Design: Can withstand free fall of 1.5m onto the floor, which is more durable during daily use.
Note:
Do not point the scanner laser to eyes.
Specification:
Name: USB Bar Code Scanner
Model: XA 10
Size: 93*71.5*177mm
Product Weight: 118g
Package Weight: 240g
Material: ABS+PC+rubber
Type of Lamp-house: Visual laser diode（VLD)
wave length 650nm
Scan Mode: Bidirectional single line scan
Scan Width: 30mm﹫scanner window，220mm﹫200mm
Scan Depth: 0-250mm (0.33mm.PCS 90%)
Scanning Speed: 200/s
Scanning Accuracy: 4mil
Intersection Angle: 30°
Altitude Angle: 75°
Deflection Angle: 65°
Print Contrast Signal: Minimum 30% reflectance
Error Rate: 1/6 million
Cable Standard Line: 2.3m
Base Power: 3.7V ~ DC5V
Working Current: 130mA (total power consumption：650mw)
Quiescent Current: 35mA
Electromagnetic Compatibility: CE & FCCDOC compliance
Operation Temperature: 0℃-45℃
Storage Temperature: 20℃-60℃
Humidity: Relative humidity 5%-95%（no condensation）
Ambient Brightness: Max. 5000 Lux (fluorescence)
Package contents:
1* XA10 Bar code scanner
1* USB cable
1* Clip
