Frame Kit Specifications:
● Wheelbase: 145mm
● Arm Plate Thickness: 3mm
● TOP and Bottom Plate Thickness: 1.5mm
● Side Plate Thickness: 1.5mm
● Material: 3k Carbon Fiber
Flight Controller Specifications:
● Micro F4 Flight Control Board ( D-Shot Version)
● MPU: MPU6000-SPI
● CPU: STM32F405RGT6, dual 8K.
● Built-in Betaflight OSD to adjust PID
● BEC Output: 5V 3A
● Size: 25 x 25mm board
● Installing Hole: 20 x 20mm, mounting holes (M2)
● Support Subs / PPM / DSMX receiver
ESC Specifications:
● 20A 2 - 4S Blhelis 4 in 1 ESC
● Input Voltage: 2S LiPo battery
● Constant Current: 20A
● Peak Current: 28A
● BEC Output: NO
● Firmware: BLhelis
● Size: 27 x 27mm (main board) 27x31mm ( including pad)
● Installing Hole: 20 x 20mm, M2
● MOS Tube: TOP QUALITY MOSFET
● Support Damped Mode, Oneshot125, Oneshot42, Multishot, Dshot150 / 300 / 600, forward and reverse
FPV Transmitter Specifications:
● Mini FPV Transmitter
● Output power: 25mW / 100mW / 200mW switchable
● Control mode:button OR Channel changes
● BAT: 7 - 26V, BEC 5V 1A
● Video system: NTSC / PAL
● Frequency: 5.8GHz 5 bands 40channels, with Raceband: 5645-5945 MHZ
Motor Specifications:
● 1408KV 3800, race edition
Camera Specifications:
● Brand name: RunCam
● Item number: Split Mini 2
● Field of View(FOV): FPV FOV 130 degree / Recording FOV 165 degree
● Video Resolution: 1080 60fps / 1080 30fps / 720 60fps
● Video File Format: MOV
● Image Resolution: 2 MP
● TV Mode: NTSC (720 x 480) / PAL (720 x 576) Switchable
● Interface : Micro USB / UART
● Max Micro SD Card Supported: 64G(need Class 6 or above, recommend Class 10 / UHS-I / UHS-II / UHS-III)
● Hole Distance of Installation: 20 x 20mm
● Dimensions: PCB 29 x 29mm / Lens Module 19 x 19mm
● Power Input: DC 5-20V
● Working Current: 650mA 5V / 270mA 12V
Buzzer Specifications:
● LED X2 BBX1
Antenna Specifications:
● Brass Antenna
Without battery and remote controller
